Accurate Measurements with the Digilent USB-2416-4AO
The Digilent USB-2416-4AO is a high-channel count USB DAQ device that provides accurate measurements with its 24-bit resolution. With 32 SE/16 analog inputs and 4 analog outputs, this device is perfect for a wide range of data acquisition applications. The isolated design ensures reliable operation, and the support for field calibration makes it easy to recalibrate the device as needed.
Features and Specifications
The Digilent USB-2416-4AO features a range of specifications that make it an ideal choice for data acquisition. The device supports thermocouple and voltage measurement, and is factory-calibrated using a NIST-traceable calibration process. The device also supports field calibration, allowing users to calibrate the device locally with the InstaCal utility.
Analog Output Functionality
The Digilent USB-2416-4AO features four 16-bit analog outputs with a +/-10 V output range. The analog outputs can be updated at a maximum rate of 1 kS/s (system dependent), making it perfect for applications that require fast data acquisition.
Digital I/O and Counter Inputs
In addition to its analog inputs and outputs, the Digilent USB-2416-4AO also features 8 digital I/O lines and 2 counter inputs. The digital I/O lines have read/write rates of 500 port or single bit reads per second, and each DIO channel is an open-drain. The digital outputs can sink up to 150 mA for direct drive applications.
Operating System Compatibility
The Digilent USB-2416-4AO is compatible with a range of operating systems, including Windows 11/10/8/7/Vista/XP 32/64-bit and Linux. This makes it easy to integrate into your existing setup.
What's in the Box
The Digilent USB-2416-4AO comes with everything you need to get started, including the USB DAQ device itself, a PS-5V2AEPS external supply, and a USB cable.
